Drainage — 110mm
110mm underground drainage — SN8 pipe, bends, junctions, gullies, hoppers, chambers and access. Trade and public welcome.
Technical diagrams are shown below the products. Product guides are on each product page.
More about Drainage 110mm
Stock includes Kayflow and Brett Martin 110mm underground pipe, single and double socket bends, junctions, bottle gullies, chambers, risers and 4in and 6in clay-to-plastic adaptors.
Call into our Leigh or Mawdesley branch to collect, or have stock items delivered next day across the North West.
Technical diagrams
Kayflow 110mm underground fitting diagrams and catalogue pages. Useful for identifying bends, junctions, gullies and hoppers before you order. Brochures are available on individual product pages.
110mm underground — fitting diagrams
Single socket pipe
Double socket coupler
Slip coupler
15° bend (single socket)
45° bend (single socket)
90° bend (single socket)
90° bend (double socket)
Adjustable bend
Rest bend (double socket)
45° junction (double socket)
45° junction (triple socket)
90° junction (double socket)
P trap
Standard bottle gully
Bottle gully (rear inlet)
Square hopper
Rectangular hopper
Rodding eye
Level invert reducer
Rainwater adaptor
Catalogue pages
Diagrams courtesy of Kayflow — supplier technical content for stockists. Product range: rainwater, waste, soil & underground.
